  • (P / NO)
SPEC.
僅外露絕緣 , 2 Holes Panel SMA Female connector
LYS CLASS NO.
SMA610B Series
PATENT
Anti-Slip Annular Section

● 阻抗：50Ω；電鍍：金或鎳

● 【使用頻率】DC ~ 6GHz, 12.4GHz, 18GHz

● SMA和RP-SMA差異?

立宇盛工業股份有限公司
● 對接介面為「母座 母針」
總長度(mm) 絕緣外露長度 主體/材質與電鍍 產 品 編 號
19.5 Φ4.1x10.0mm 黃銅/鍍金 SMA610B-19.5/10
21.0 Φ4.1x11.5mm 黃銅/鍍金 SMA610B-21/11.5
19.5 Φ4.1x10.0mm 不鏽鋼/鈍化 SMA610B-19.5/10(ST)
21.0 Φ4.1x11.5mm 不鏽鋼/鈍化 SMA610B-21/11.5(ST)



SMA Female Panel 2 Holes Exposed PTFE     -Relative - 18GHz SMA-
